Water leak rear seat

Discussion in '1st Gen Tundras (2000-2006)' started by Jwow530, Feb 4, 2017.

  1. Feb 4, 2017 at 9:33 PM
    #1
    Jwow530

    Jwow530 [OP] New Member

    Joined:
    Dec 15, 2016
    Member:
    #5575
    Messages:
    18
    Gender:
    Male
    First Name:
    Jay
    Vehicle:
    2002 Toyota Tundra TRD
    hello I been trying to find the water leak behind my seat on my access cab I took out the rear seat to see if it was leaking from the vents but it seems like it coming from the top here's some pics thanks


  2. Feb 4, 2017 at 10:31 PM
    #2
    bobeast

    bobeast really old member

    Joined:
    Feb 11, 2015
    Member:
    #960
    Messages:
    1,527
    Gender:
    Male
    First Name:
    Bob
    Hollister, CA
    Vehicle:
    2008 DC
    - Bull Bar - LED Bunny Burners - AMP retractable running boards - Headlight leveling retrofit - P3 Brake Controller - 60% rear seat delete - relocation of Sub to rear wall - Bilstein 5100 x4, top setting with 2 shims per side - Coach builder +2 rear shackles w/carrier bearing drop - Firestone Air bags - on-board compressor with auto-leveling - Dual Undercover Swing Boxes. - P285/65/R20 (34.6") BFG TA KO2's - TRD Front skid plate - Pop & Lock Tailgate lock - Remote Tailgate mod - LED Headlights - Nav Bypass - iPhone integration - Serius/XM retrofit - 25% front tint - Bizon electric tonneau cover - Power folding tow mirror upgrade - 2010+ leveling Headlight mod - Auto-fold mirror mod. - one-touch lane changer mod - Flash to open garage opener mod - Rigid H/L fog light upgrade - Pushbutton / Remote start mod.
    My guess would be the 3rd brake light.

  3. Feb 4, 2017 at 10:36 PM
    #3
    Jwow530

    Jwow530 [OP] New Member

    Joined:
    Dec 15, 2016
    Member:
    #5575
    Messages:
    18
    Gender:
    Male
    First Name:
    Jay
    Vehicle:
    2002 Toyota Tundra TRD
    How would I take it off I try early there was 4 screws and the len just came off not the whole thing

  4. Feb 4, 2017 at 10:36 PM
    #4
    Midnighttaco08

    Midnighttaco08 High Quality H2O Inspector

    Joined:
    Jan 7, 2017
    Member:
    #5850
    Messages:
    485
    Gender:
    Male
    First Name:
    Sam
    Gilbert, AZ
    Vehicle:
    2017 Quicksand TRD OR 4x4 2008 Indigo Ink Tacoma TRDOR
    None yet!
    Yep, I'd guess 3rd brake light.

    My Tacoma had that issue about a year ago... but was caused because the company who wrapped my roof did not replace the seal with a new one and it leaked like hell.

  5. Feb 4, 2017 at 11:13 PM
    #5
    bobeast

    bobeast really old member

    Joined:
    Feb 11, 2015
    Member:
    #960
    Messages:
    1,527
    Gender:
    Male
    First Name:
    Bob
    Hollister, CA
    Vehicle:
    2008 DC
    - Bull Bar - LED Bunny Burners - AMP retractable running boards - Headlight leveling retrofit - P3 Brake Controller - 60% rear seat delete - relocation of Sub to rear wall - Bilstein 5100 x4, top setting with 2 shims per side - Coach builder +2 rear shackles w/carrier bearing drop - Firestone Air bags - on-board compressor with auto-leveling - Dual Undercover Swing Boxes. - P285/65/R20 (34.6") BFG TA KO2's - TRD Front skid plate - Pop & Lock Tailgate lock - Remote Tailgate mod - LED Headlights - Nav Bypass - iPhone integration - Serius/XM retrofit - 25% front tint - Bizon electric tonneau cover - Power folding tow mirror upgrade - 2010+ leveling Headlight mod - Auto-fold mirror mod. - one-touch lane changer mod - Flash to open garage opener mod - Rigid H/L fog light upgrade - Pushbutton / Remote start mod.
    I think you have to go behind the headliner from the inside.

    NewImprovedRon likes this.
  6. Feb 4, 2017 at 11:14 PM
    #6
    Jwow530

    Jwow530 [OP] New Member

    Joined:
    Dec 15, 2016
    Member:
    #5575
    Messages:
    18
    Gender:
    Male
    First Name:
    Jay
    Vehicle:
    2002 Toyota Tundra TRD
    I wondering why headliner not wet

  7. Feb 4, 2017 at 11:20 PM
    #7
    Midnighttaco08

    Midnighttaco08 High Quality H2O Inspector

    Joined:
    Jan 7, 2017
    Member:
    #5850
    Messages:
    485
    Gender:
    Male
    First Name:
    Sam
    Gilbert, AZ
    Vehicle:
    2017 Quicksand TRD OR 4x4 2008 Indigo Ink Tacoma TRDOR
    None yet!
    If it's like my 08 Tacoma, it is just a adhesive strip like double sided tape in addition to the screws.

    After removing the screws, use a panel tool to remove. Put some blue painters tape on the paint where the panel tool goes to protect the paint.

    This is only if it's the same at the Tacoma :anonymous:

  8. Feb 4, 2017 at 11:37 PM
    #8
    Jwow530

    Jwow530 [OP] New Member

    Joined:
    Dec 15, 2016
    Member:
    #5575
    Messages:
    18
    Gender:
    Male
    First Name:
    Jay
    Vehicle:
    2002 Toyota Tundra TRD
    I been looking online some say that it have two bolt inside the headliner so I gonna make sure to check before breaking anything

  9. Feb 5, 2017 at 12:16 PM
    #9
    delz05

    delz05 Old relic... Living and Loving Life!!!

    Joined:
    Jun 8, 2015
    Member:
    #1393
    Messages:
    108
    Gender:
    Male
    BOSTON
    Vehicle:
    2005 Tundra Limited
    Work in progress...
    Wouldn't hurt to check the rear window as well... I had to pop out mine 2 years ago because of a water leak.

  10. Feb 5, 2017 at 12:27 PM
    #10
    831Tun

    831Tun crazy Bastrd

    Joined:
    Jun 7, 2016
    Member:
    #3549
    Messages:
    10,906
    Gender:
    Male
    First Name:
    Warren
    Santa Cruz
    Vehicle:
    '16 CM limited
    TC LT w/ king 2.5 C/O and bypass, ADS bypass rear, Toytech shackles, TRD dual exhaust dumped, KM3 37s on Method standard +18. N_Fab front bumper, Westin rear w/ hitch relocate, RCI skids, Desert Eagle tranny skid, All Pro sliders, ARB dual compressor, 5.29 gears and ARB rear locker
    Removing the headliner is pretty straight forward. You only need to drop the back half. Removing the entire thing isn't necessary. Watch out for the 2 nuts that secure the 3rd brake light, they're EASY to drop and hard to retrieve. A magnet on an extendable wand can be very handy.

    NewImprovedRon likes this.
  11. Feb 5, 2017 at 12:29 PM
    #11
    Jwow530

    Jwow530 [OP] New Member

    Joined:
    Dec 15, 2016
    Member:
    #5575
    Messages:
    18
    Gender:
    Male
    First Name:
    Jay
    Vehicle:
    2002 Toyota Tundra TRD
    How would I know if it's leaking from rear windows?

  12. Feb 5, 2017 at 2:12 PM
    #12
    831Tun

    831Tun crazy Bastrd

    Joined:
    Jun 7, 2016
    Member:
    #3549
    Messages:
    10,906
    Gender:
    Male
    First Name:
    Warren
    Santa Cruz
    Vehicle:
    '16 CM limited
    TC LT w/ king 2.5 C/O and bypass, ADS bypass rear, Toytech shackles, TRD dual exhaust dumped, KM3 37s on Method standard +18. N_Fab front bumper, Westin rear w/ hitch relocate, RCI skids, Desert Eagle tranny skid, All Pro sliders, ARB dual compressor, 5.29 gears and ARB rear locker
    Maybe try a hose? Not too much pressure, just wet it.

    040Tundra likes this.
  13. Feb 5, 2017 at 4:54 PM
    #13
    Jwow530

    Jwow530 [OP] New Member

    Joined:
    Dec 15, 2016
    Member:
    #5575
    Messages:
    18
    Gender:
    Male
    First Name:
    Jay
    Vehicle:
    2002 Toyota Tundra TRD
    Looks like no bolts inside the headliner just the screws in the 3rd break light well I open it up looks good but the gasket looks kind old so I clean it and put sealant on it so now I'm waiting for that to dry up and see if it's gonna leak some where else

    TX-TRD1stGEN likes this.
  14. Feb 6, 2017 at 5:48 PM
    #14
    Nor7

    Nor7 Chilton Manual Guy

    Joined:
    Oct 19, 2015
    Member:
    #1989
    Messages:
    1,332
    Gender:
    Male
    Texas
    Vehicle:
    2007 Tundra Limited CM, 5.7L
    I've seen someone else have this issue and it ended up being the window leaking. But 3rd brake light seems like a good candidate too. Last time I replaced a light up there, the seal was almost to a dry cracked point.

  15. Feb 6, 2017 at 6:04 PM
    #15
    Jwow530

    Jwow530 [OP] New Member

    Joined:
    Dec 15, 2016
    Member:
    #5575
    Messages:
    18
    Gender:
    Male
    First Name:
    Jay
    Vehicle:
    2002 Toyota Tundra TRD
    Replace 3rd break light seal now it's still leaking seem like it might be the rear windows that's the next step

  16. Feb 7, 2017 at 9:10 AM
    #16
    Jwow530

    Jwow530 [OP] New Member

    Joined:
    Dec 15, 2016
    Member:
    #5575
    Messages:
    18
    Gender:
    Male
    First Name:
    Jay
    Vehicle:
    2002 Toyota Tundra TRD
    I call two auto glass shop they say that can't take out the rear window it can break and they are supposed to be glue on there any help how I can get it seal or anyone remove the rear window befor?

  17. Feb 7, 2017 at 9:18 AM
    #17
    bobeast

    bobeast really old member

    Joined:
    Feb 11, 2015
    Member:
    #960
    Messages:
    1,527
    Gender:
    Male
    First Name:
    Bob
    Hollister, CA
    Vehicle:
    2008 DC
    - Bull Bar - LED Bunny Burners - AMP retractable running boards - Headlight leveling retrofit - P3 Brake Controller - 60% rear seat delete - relocation of Sub to rear wall - Bilstein 5100 x4, top setting with 2 shims per side - Coach builder +2 rear shackles w/carrier bearing drop - Firestone Air bags - on-board compressor with auto-leveling - Dual Undercover Swing Boxes. - P285/65/R20 (34.6") BFG TA KO2's - TRD Front skid plate - Pop & Lock Tailgate lock - Remote Tailgate mod - LED Headlights - Nav Bypass - iPhone integration - Serius/XM retrofit - 25% front tint - Bizon electric tonneau cover - Power folding tow mirror upgrade - 2010+ leveling Headlight mod - Auto-fold mirror mod. - one-touch lane changer mod - Flash to open garage opener mod - Rigid H/L fog light upgrade - Pushbutton / Remote start mod.
    Ever seen a dead cat in a tree? Somehow others manage to replace their rear window, else you'd see a bunch of trucks running around with duct-tape on the rear.

    Any good auto-body shop should be able to remove, reseal, and replace your rear window.

    NewImprovedRon likes this.
  18. Feb 7, 2017 at 3:15 PM
    #18
    831Tun

    831Tun crazy Bastrd

    Joined:
    Jun 7, 2016
    Member:
    #3549
    Messages:
    10,906
    Gender:
    Male
    First Name:
    Warren
    Santa Cruz
    Vehicle:
    '16 CM limited
    TC LT w/ king 2.5 C/O and bypass, ADS bypass rear, Toytech shackles, TRD dual exhaust dumped, KM3 37s on Method standard +18. N_Fab front bumper, Westin rear w/ hitch relocate, RCI skids, Desert Eagle tranny skid, All Pro sliders, ARB dual compressor, 5.29 gears and ARB rear locker
    +1

  19. Feb 12, 2017 at 10:25 AM
    #19
    delz05

    delz05 Old relic... Living and Loving Life!!!

    Joined:
    Jun 8, 2015
    Member:
    #1393
    Messages:
    108
    Gender:
    Male
    BOSTON
    Vehicle:
    2005 Tundra Limited
    Work in progress...
    I have removed the tundra rear window, no issue at all. Remove the 4 nuts, cut from inside with extended razor knife, push gently with helper on the outside handling the window as it releases. Just painted a Tacoma (06), had to pull the rear window as well. Glass company said the same thing... "can't pull it... it will break...". They wanted 650.00. Myself and a friend had it out in 30 minutes... no issue at all.

    NewImprovedRon likes this.
  20. Feb 12, 2017 at 10:46 AM
    #20
    NewImprovedRon

    NewImprovedRon Hey! Get off my grass!

    Joined:
    Jul 8, 2015
    Member:
    #1501
    Messages:
    13,050
    Gender:
    Male
    First Name:
    Ron
    Bentonville, AR
    Vehicle:
    2015 Radiant Red TSS Doublecab 4X4 Off Road
    Deck rail system, Bed divider, door sill protectors, LED reverse light bars, Aries Bull Bar with 28" 180 watt LED light bar, LED step lights, LED bed lights, driver-side grab handle, TRD Rear Sway Bar, BedRug bed mat and tailgate mat, Morimoto Fog Lights, more to come.....
    How tough is the installation on a new one?

  21. Feb 13, 2017 at 9:55 AM
    #21
    delz05

    delz05 Old relic... Living and Loving Life!!!

    Joined:
    Jun 8, 2015
    Member:
    #1393
    Messages:
    108
    Gender:
    Male
    BOSTON
    Vehicle:
    2005 Tundra Limited
    Work in progress...
    Just do a good job of removing the old silicone, take care of any rust that may have started, use the proper glass adhesive, press it in, tighten the 4 nuts, add some tape to the exterior to secure it, less that an hour from start to finish...

    NewImprovedRon likes this.
  22. Dec 17, 2018 at 2:59 PM
    #22
    Professional Hand Model

    Professional Hand Model A.K.A ‘Golden Hands’

    Joined:
    Apr 29, 2018
    Member:
    #14878
    Messages:
    15,058
    Gender:
    Male
    First Name:
    Fred
    ‘Somewhere’... a State of Mind
    Vehicle:
    2002 Tundra SR5 4WD 4.7L AC Silver Metallica
    Hand Protectors
    Check out post #2563 for pictures and details on the fix the OP is looking for. Its pretty simple actually and costs nothing but about 40 minutes of your time. This link should take you right to what I did to solve the problem. It makes sense once you see the pics.

    Basically, there are weep holes in the sliding window rubber gasket AND the track that said rubber gasket sits in that need to be flushed/cleaned out.

    https://www.tundras.com/threads/what-have-you-done-to-your-1st-gen-tundra-today.2558/page-86


    Attached Files:

  23. Mar 2, 2019 at 10:23 PM
    #23
    kb7

    kb7 New Member

    Joined:
    Oct 7, 2018
    Member:
    #20258
    Messages:
    42
    USA
    Vehicle:
    2003 Tundra SR5 TRD 4x4
    I'm just following up on this issue as I'm having the exact same problem on my 03 access cab (36k mi ;)). Does the sliding window's rubber track simply pull out?

    I'm hoping this solves my leak so I don't have to replace the rear window... Planning on attempting it tomorrow

  24. Mar 2, 2019 at 10:35 PM
    #24
    kcaustin66

    kcaustin66 New Member

    Joined:
    Jan 23, 2018
    Member:
    #12407
    Messages:
    439
    Gender:
    Male
    First Name:
    kevin
    Palestine Texas (East Texas)
    Vehicle:
    2015 Toyota Tundra CM 1794 4wd
    3” lift, black step bars, aftermarket wheels, LT305/55R20 was this way when I brought it.
    Have you replaced the light bulbs maybe to LEDs, did the seal get reinstalled right, possible cause of leaking water..
    Just a thought

  25. Mar 2, 2019 at 10:53 PM
    #25
    kb7

    kb7 New Member

    Joined:
    Oct 7, 2018
    Member:
    #20258
    Messages:
    42
    USA
    Vehicle:
    2003 Tundra SR5 TRD 4x4
    Thanks for the reply. Swapped out the third breaklight assembly with a new unit. Comes with a double sided adhesive backing, pretty standard swap but the interior of the header behind the light was dry upon removal of the old unit. It's been raining pretty consistently, which is a rarity for CA, and should have still been damp when I made the change.
    Didn't switch out to LEDs, which is on the radar as I no the current light set up likes to burn through the housing...

  26. Mar 3, 2019 at 6:48 AM
    #26
    Professional Hand Model

    Professional Hand Model A.K.A ‘Golden Hands’

    Joined:
    Apr 29, 2018
    Member:
    #14878
    Messages:
    15,058
    Gender:
    Male
    First Name:
    Fred
    ‘Somewhere’... a State of Mind
    Vehicle:
    2002 Tundra SR5 4WD 4.7L AC Silver Metallica
    Hand Protectors
    Yes it pulls out, but not all the way as the window is holding it down. Slide the window back and do one side. Slide it over and complete the other portion. No more leaks.

    kb7 likes this.
  27. Sep 10, 2019 at 1:26 PM
    #27
    2000Strong

    2000Strong Just a dude and his truck

    Joined:
    Jan 8, 2019
    Member:
    #24183
    Messages:
    140
    Gender:
    Male
    First Name:
    Benjamin
    Washington
    Vehicle:
    2000 Maroon Tundra, AC, Premium Audio, SR5 4.7
    All LED Interior lights, New Headlights, Break Controler, LineX Bedliner.
    I’m having the same problem I can’t seem to find where it’s coming from. Has anyone found the cause?

  28. Sep 10, 2019 at 1:57 PM
    #28
    kb7

    kb7 New Member

    Joined:
    Oct 7, 2018
    Member:
    #20258
    Messages:
    42
    USA
    Vehicle:
    2003 Tundra SR5 TRD 4x4
    Mine was from the seal on the slider window. Cheap fix was to purchase some boat clear sealant and apply it along the edges of the trim both outside and inside the slider. Water was leaking to the bottom of slider rubber track. Nothing was obscuring the flow, just the seal was failing to keep out the excess which flowed to the corners and down to the carpet.

  29. Sep 11, 2019 at 12:06 AM
    #29
    2000Strong

    2000Strong Just a dude and his truck

    Joined:
    Jan 8, 2019
    Member:
    #24183
    Messages:
    140
    Gender:
    Male
    First Name:
    Benjamin
    Washington
    Vehicle:
    2000 Maroon Tundra, AC, Premium Audio, SR5 4.7
    All LED Interior lights, New Headlights, Break Controler, LineX Bedliner.
    Oh ok, like the channel the rear glass slides in? It kinda just appears on the carpet I took the seats out and everything and nothing was wet but the carpet.

  30. Sep 11, 2019 at 3:19 AM
    #30
    FirstGenVol

    FirstGenVol The "Mangler"

    Joined:
    Dec 13, 2018
    Member:
    #22934
    Messages:
    7,709
    First Name:
    Erik
    TN
    Vehicle:
    2002 SR5 4x4 AC
    Too many
    Go to Hand Models build thread and he shows this issue. That channel has drain holes in the bottom that get clogged. You May need to go through and clean it out. Should be an easy fix.
