Timing Belt on 05 Tundra 4.7 2UZ-FE

Discussion in '1st Gen Tundras (2000-2006)' started by Andrewb5, Sep 13, 2022.

  1. Sep 13, 2022 at 11:12 PM
    #1
    Andrewb5

    Andrewb5 [OP] New Member

    Joined:
    Jan 2, 2021
    Member:
    #57012
    Messages:
    2
    Gender:
    Male
    Vehicle:
    2005 Tundra Double Cab
    I've been having a stutter from the engine while idling in gear and have replaced plugs & coils to no avail. I did some research and have come to the conclusion that my timing belt could have slipped. I would think this to be unlikely but I am approaching 250k miles and to my knowledge the timing belt has never been replaced. I've bought the Gates TCKWP298 timing belt kit and will be working on it this weekend. I'll only have 2 days home from college to get the entire job done. Does anyone have any pointers? And is it possible to change the timing belt without removing the A/C compressor? I'm also not certain about lining the belt up. I know the mark on each pulley should line up with the I mark, but I've seen some people line up the marks on the belt with whichever letter is to the side of the I, while others line them up with the same I mark as the pulley. Anyone have any insight on this? Thanks in advance.

  2. Sep 13, 2022 at 11:42 PM
    #2
    NickB_01TRD

    NickB_01TRD You don't need less cars, just more driveway.

    Joined:
    Jun 16, 2021
    Member:
    #64346
    Messages:
    1,080
    Gender:
    Male
    First Name:
    Nick
    KY
    Vehicle:
    01 Tundra SR5 TRD AC
    I would say bare minimum you wouldn't want to rush this job. Toyota dealers can do it for somewhere around $1000
    You can pull one of the plastic covers back on the driver or passenger side (driver is easier) and check the belts condition. How long have you had the truck? If that belt breaks it could turn that engine into a paperweight.

    irhunter and joseph_womack like this.
  3. Sep 14, 2022 at 5:25 AM
    #3
    shifty`

    shifty` trying to remember when but it makes me dizzy

    Joined:
    Jun 20, 2020
    Member:
    #48239
    Messages:
    6,447
    ATL
    Vehicle:
    '06 AC Limited 4WD + LSD & TOW PKG
    Can't recommend watching the process from start to finish so you know what you're in for. The 1st of these videos is one of my favorites giving a lot of the warnings/issues to be aware of. The 2nd video is another one that other folks around here like from a Toyo mech. Either way, if you suspect the belt has never been changed, you're gambling with the life of your vehicle every time you start it up. It takes 5 minutes and a 10mm ratched to loosen the bolts enough to pull back either of the timing covers to check the belt for cracks. Toyota recommends changing every 9yrs or 90k miles, whichever is first. I think 10yrs/100k is plenty fine and some guys have made it as long as you w/o changing for sure, but others have had their engine grenade via old belts snapping and jumping before 175k miles. It's all a crapshoot.

    https://www.youtube.com/watch?v=HPpzLJwoxng

    https://www.youtube.com/watch?v=Z46cM-Bw1rI

    N84434, des2mtn, alb1k and 2 others like this.
  4. Sep 14, 2022 at 2:00 PM
    #4
    Kimosabe

    Kimosabe Slacker

    Joined:
    Jul 28, 2020
    Member:
    #50004
    Messages:
    573
    Gender:
    Male
    First Name:
    Chris
    Sun Valley, Idaho
    Vehicle:
    03 Tundra AC TRD

    Can we get these input in the info dump thread, or add them to some sticky post that references repairs?

    FrenchToasty and shifty` like this.
  5. Sep 14, 2022 at 2:10 PM
    #5
    Kimosabe

    Kimosabe Slacker

    Joined:
    Jul 28, 2020
    Member:
    #50004
    Messages:
    573
    Gender:
    Male
    First Name:
    Chris
    Sun Valley, Idaho
    Vehicle:
    03 Tundra AC TRD
    I agree with the above. Take a look at the belt and see what kind of shape it is in. That will tell you what your in for. It might be an easier situation to fix.
    Speaking of, have you changed the air filter? Throttle body cleaner? MAF cleaner? A can or two of Seafoam in the tank?

    If you haven't done this before, watch the videos and do your research beforehand so you don't break everything down and then realize your missing something like the belt tensioner and get stuck. Or you can have the dealer do it and take that bit of stress off your plate. Might be worth it in the short-run.

    I haven't done the TB on the tundra, but after doing it on my 4runner I would recommend buying/renting the specialty tools that are recommended. If you need the truck back up and running, don't assume you can just get by without the proper tools.

  6. Sep 14, 2022 at 2:26 PM
    #6
    shifty`

    shifty` trying to remember when but it makes me dizzy

    Joined:
    Jun 20, 2020
    Member:
    #48239
    Messages:
    6,447
    ATL
    Vehicle:
    '06 AC Limited 4WD + LSD & TOW PKG
    We'd started chatting through that several months back, but I don't know where we ever landed. It maybe started with a poll, and then went nowhere after?

    Ultimately, I think we need someone in the 1st Gen forum with moderation power, but only over the 1st Gen subforum itself, I think. Someone that can talk with all of the regulars here, make choices on what to stick or unstick, and work on a few "global info" threads. Ever since Pinay left, we get stuff done when asked, but I think we need some dedicated support, even if just for a couple of months.

    Not to mention, while you'll likely pay several hundred more having the dealer (or a trusted Toyota-specific shop for maybe a few hundred more) do the work, you'd get the side benefit of walking away knowing a professional that's probably done it before finished up the work, and you've got some recourse if anything is effed up.

    Aerindel and Kimosabe like this.
  7. Sep 14, 2022 at 8:47 PM
    #7
    NickB_01TRD

    NickB_01TRD You don't need less cars, just more driveway.

    Joined:
    Jun 16, 2021
    Member:
    #64346
    Messages:
    1,080
    Gender:
    Male
    First Name:
    Nick
    KY
    Vehicle:
    01 Tundra SR5 TRD AC
    I'd vote you in for that in a heartbeat @shifty`

    shifty` and Aerindel like this.
  8. Sep 14, 2022 at 9:01 PM
    #8
    Winning8

    Winning8 New Member

    Joined:
    Jul 4, 2019
    Member:
    #32819
    Messages:
    1,513
    Gender:
    Male
    Da Bay Area
    Vehicle:
    2019 MGM DC 4x4 SR5
    Mumba 18x9 ET 12, BFG KO2, FOX suspension, diamond back HD cover w/ rack, LED head & fog light bulb, TRD rear sway bar, timbren enhancement, avs auto shade, bench seat cover
    I would just let some professional do the job, if op haven’t done a timing belt job b4.

    shifty` likes this.
  9. Sep 14, 2022 at 10:00 PM
    #9
    Aerindel

    Aerindel New Member

    Joined:
    Jan 31, 2019
    Member:
    #25399
    Messages:
    1,180
    Gender:
    Male
    Montana
    Vehicle:
    2000 Tundra AC, SR5, 4.7 V8 4WD, 325,00ish miles.
    A 19 year old neighbor kid did it for me, its been working perfectly so it can't be that hard, no offense to the neighbor kid.

  10. Sep 15, 2022 at 7:05 AM
    #10
    des2mtn

    des2mtn Ridgeline with a 4-speed

    Joined:
    Jul 1, 2020
    Member:
    #48721
    Messages:
    2,484
    SoCal 760
    Vehicle:
    2004 Black DC Limited 4x4
    Desert and mountain pinstripes
    Plan for three days, take a day and a half maybe two full days. I hadn't done a TB before, but it took me the better part of a day and a half taking my time and replacing other stuff in there.

    Bag and label all the parts you take off and keep a clean work space. Yes, move the engine accessories out of the way (AC compressor, PS pump, alternator) and take the radiator out too. Buy or rent the tool to get the crank bolt out that holds the crank. Rent a harmonic balancer puller, yours might come off by hand.

    It seems daunting at first, but if you're semi-handy with tools you can DIY. Just do plenty of research before hand and watch the videos linked above repeatedly.

    shifty` likes this.
  11. Sep 15, 2022 at 8:12 AM
    #11
    Winning8

    Winning8 New Member

    Joined:
    Jul 4, 2019
    Member:
    #32819
    Messages:
    1,513
    Gender:
    Male
    Da Bay Area
    Vehicle:
    2019 MGM DC 4x4 SR5
    Mumba 18x9 ET 12, BFG KO2, FOX suspension, diamond back HD cover w/ rack, LED head & fog light bulb, TRD rear sway bar, timbren enhancement, avs auto shade, bench seat cover
    Shop only call for 4hrs for a timing belt w/ water pump job…1-2 days should be enough with beer breaks…lol

  12. Sep 15, 2022 at 6:12 PM
    #12
    Bilgepump

    Bilgepump New Member

    Joined:
    Jun 30, 2022
    Member:
    #80138
    Messages:
    46
    Vehicle:
    '06 Sequoia Limited 4.7L VVT-i 2WD
    All Stock
    Here is a video by a Toyota mechanic doing a timing belt change on a 2006 Tundra 4.7......

    By far, the best video I have seen on replacement of timing belt.......

    Trust us.....use the "T" mark for putting belt on.....camshafts will not unload & shift on you.....

    I believe this guy has a very useful hint for getting belt on without frustration.......watch carefully 4:20 to 5:20 mark in video......turn off music in video...very irritating....

    we are also here to help you......a lot of us have been down this road many times and are very familiar with the timing belt process.

    https://www.youtube.com/watch?v=Z46cM-Bw1rI&t=378s

    Tundra2 likes this.
  13. Sep 15, 2022 at 7:04 PM
    #13
    shifty`

    shifty` trying to remember when but it makes me dizzy

    Joined:
    Jun 20, 2020
    Member:
    #48239
    Messages:
    6,447
    ATL
    Vehicle:
    '06 AC Limited 4WD + LSD & TOW PKG
    Same as 2nd video in reply #3 above :rofl:

    I posted that with you in mind, fwiw.

    Tundra2 likes this.
  14. Sep 16, 2022 at 10:52 AM
    #14
    N84434

    N84434 In the Frozen Tundra

    Joined:
    Jan 22, 2020
    Member:
    #41580
    Messages:
    969
    Gender:
    Male
    First Name:
    Jim
    Milwaukee WI.
    Vehicle:
    2001 Limited TRD
    OP went radio silent... Perhaps he realized this was a bit more than he wanted to bite off???

    Tundra2 likes this.
  15. Sep 16, 2022 at 12:10 PM
    #15
    Baller

    Baller New Member

    Joined:
    Jul 22, 2018
    Member:
    #17275
    Messages:
    567
    Gender:
    Male
    Vehicle:
    '05 Tundra SR5 DC
    Here's the post I started a bit ago. Like you said, it didn't end up going anywhere. I just updated the initial post to include the two videos posted here.
    https://www.tundras.com/threads/timing-belt-master-thread-sticky.107240/

    shifty` likes this.
  16. Sep 19, 2022 at 7:04 AM
    #16
    Woodyxr

    Woodyxr New Member

    Joined:
    Monday
    Member:
    #83567
    Messages:
    2
    Gender:
    Male
    Vehicle:
    2004 DC, 2006 DC
    I just did mine over the weekend. I spent about 9 hours working time between Friday and Saturday. Biggest pains were the oem radiator hose clamps and the rear bolt on the AC compressor. Not a terrible job just lots of steps and time consuming.

    Teutonics, des2mtn and shifty` like this.
