Fox 2.0 question

I have a 2016 tundra platinum. I plan to buy fox 2.0 coilovers with the rear shocks as well. I would like to fit decent size tires with a 17”-18” wheel. I need to know if I need to buy a spacer for the rear and new upper control arms.
Thanks!



The Fox 2.0 units for the front come pre-set at 2" of lift. If your under 3" of lift, generally you won't need new UCAs. Just adding the Fox's on the front will get you near level, with a possible 3/4 - 1" rake, so you may not need spacers (blocks) in the rear.



So do you know what size tires I can fit with the fox 2.0



You're more than likely looking at the 285/70/18 and may have slight trimming toward the front of the front fenders. I don't have any lift and run 285/65/18 with aftermarket wheel that have a different offset than stock, and I just slightly rub the front of the front inner plastic liner when reversing out of the driveway. I already pulled the little air deflectors in front of the front wheels.



WIth the Fox's up front, you'll be sitting about the same height as the TRD Pro. Look through this thread about that tire size:

https://www.tundras.com/threads/285-70r18-ridge-grappler-on-2019-pro.33526/



I would highly recommend looking at the Fox 2.5 R/R shocks instead of the smaller 2.0 shocks. For not much more money, you will get a much better ride for that size of a truck. Like mentioned above, 2" or taller you should get new upper control arms.
https://accutuneoffroad.com/product...oducts/toyota/tundra/toyota-tundra-2007-2019/



i went with the fox stage 4 ultimate kit (2.5" front / 2.0" rear) with res, love the ride and that it's a fully adjustable system. really happy. to me ride feels better than oem.

can't answer the tire question op. i'm on 20" wheels and 33's.
