Dash Clock Replacement

Discussion in '1st Gen Tundras (2000-2006)' started by tundrainsc, Aug 3, 2022.

  1. Aug 3, 2022 at 4:54 AM
    #1
    tundrainsc

    tundrainsc [OP] Happy Tundra 1st Gen

    Joined:
    Nov 29, 2019
    Member:
    #39306
    Messages:
    100
    Gender:
    Male
    Vehicle:
    06 Limited 4.7 2WD
    My clock has quit working on my 06 DC Limited. It was so dim I could never read it anyway during daylight. I would like a small thin clock to stick on the dash where the factory installed one is. Can go on without a working clock if I can't find a nice looking stick on. If anyone has found a replacement pls post picture and seller info

  2. Aug 3, 2022 at 5:26 AM
    #2
    shifty`

    shifty` Cockroach dreams, the human dust of pain

    Joined:
    Jun 20, 2020
    Member:
    #48239
    Messages:
    21,744
    ATL
    Vehicle:
    '06 AC Limited V8/4WD
    (see signature for truck info)
    Interesting. I seem to remember the clock is just part of the 4WD switch assembly panel, I just can't remember if it was a modular component or not, or something you could easily replace.

    I really need to take pics of the back of my center dash panel next time I've got it off to work on stuff.

  3. Aug 3, 2022 at 5:30 AM
    #3
    Shanet421

    Shanet421 (Semi) New Member

    Joined:
    Oct 17, 2020
    Member:
    #53708
    Messages:
    1,294
    Gender:
    Male
    San Diego,CA
    Vehicle:
    2013 CM 5.7L 4x4 SR5 Super White
    Inexpensive options

    Novinex Ultra-Thin LCD Digital Display Car Vehicle Dashboard Clock with Calendar(Color:Black) https://www.amazon.com/dp/B07DYRQJCV

    YOUNGFLY Mini Car Clock Auto Car Truck Dashboard Time Self-Adhesive Bracket Vehicle Electronic Digital Clock https://www.amazon.com/dp/B07L13BCXR

  4. Aug 3, 2022 at 6:15 AM
    #4
    Jack McCarthy

    Jack McCarthy Truck repair enthusiast; Rust Aficionado

    Joined:
    Nov 2, 2020
    Member:
    #54409
    Messages:
    8,505
    Gender:
    Male
    First Name:
    Bill
    North of Boston
    Vehicle:
    02 Tundra AC SR5 V8 4x4
    You might be able to fix it if you can get the clock circuit out of the bezel assembly. Supposedly a lot of the failures are due to cracked solder joints that just need touch up with a soldering iron.

    shifty` likes this.
  5. Aug 3, 2022 at 7:19 AM
    #5
    shifty`

    shifty` Cockroach dreams, the human dust of pain

    Joined:
    Jun 20, 2020
    Member:
    #48239
    Messages:
    21,744
    ATL
    Vehicle:
    '06 AC Limited V8/4WD
    (see signature for truck info)
    ... or solder in a light-gauge jumper after you test traces for continuity.

    I've also heard the HVAC controls having solder joint cracking issues. And there's a company somewhere out there who'll fix the board(s) if you remove and ship to them. I'd need to dig for the info. I have it stuck in my head theo ne company others mentioned is in TX.

    Jack McCarthy[QUOTED] likes this.
  6. Aug 3, 2022 at 7:48 AM
    #6
    BubbaW

    BubbaW Been Real

    Joined:
    Aug 19, 2019
    Member:
    #34845
    Messages:
    3,280
    First Name:
    Bubba
    Where Eagles Nest
    Vehicle:
    04 DC LTD 4X4 4.7 V8
    T150 Lover
    They did not make it impossible to touch up soldering but they sure made it a challenge. Had that whole circuit board off last year checking the 4WD drive switches and general look see. The clock module has about 30 paper clip size prongs that go downwards about 1 1/2" to circuit board.

    Climate Control Clock.jpg

    Climate Control Ckt Board.jpg

    Last edited: Aug 3, 2022
  7. Aug 3, 2022 at 8:13 AM
    #7
    shifty`

    shifty` Cockroach dreams, the human dust of pain

    Joined:
    Jun 20, 2020
    Member:
    #48239
    Messages:
    21,744
    ATL
    Vehicle:
    '06 AC Limited V8/4WD
    (see signature for truck info)
    Huh. Thanks for posting that, Bubba

    So it looks like it's a shared PCB with the 4WD controls (@Scuddog this may be interesting to you). So if you got a working board, it wouldn't be too difficult to board-swap, a couple of screws to get there, as long as the donor truck was (ideally) same year, with same drivetrain (2WD/4WD). So not a horrible fix to replace the clock by way of replacing its circuit board.

    I don't see any HVAC controls through that specific PCB. I do see the little 5-wire jumper over to the airbag light/hazard control (or whatever). I'm surprised to see two power bulkheads on the PCB with the clock, unless one of those is feeding out to somewhere else for the 4WD buttons. @Scuddog that's kinda what I'm wondering here with your buttons. Maybe one of those connectors is loose, or maybe you've got a bad trace on your board?

    EWD would let you figure out the pinout for each connector and what power (if any) should be on each.
