6112 top setting rear 1 Toytec shackles 5100

Discussion in '1st Gen Tundras (2000-2006)' started by quinterora8, May 21, 2020.

  1. May 21, 2020 at 5:13 PM
    #1
    quinterora8

    quinterora8 [OP] New Member

    Joined:
    May 21, 2020
    Member:
    #46890
    Messages:
    26
    Gender:
    Male
    First Name:
    Ruben
    SoCal
    Vehicle:
    2020 CM TRD
    6112/5100 & UCA
    Hello everyone, )brand new to forum) I have a couple of questions I searched and couldn’t find an a clear answer. I have 20 crew max 4wd

    i ordered the Bilstein 6112 and 5100 for rear accompanied with Toytec shackles. I’m set on doing the top setting and wanted to know if one inch rear lift will be enough to have it leveled. 5100’s say they are good for 1inch lift if I go to the 1.5 setting will I need to replace rear shocks? Will I need to install carrier bearing drop? I don’t off road much other than a couple of dirt fire roads to get to campsites.
    Would love to see some pictures of this setup if you’re running it

  2. May 21, 2020 at 5:30 PM
    #2
    Professional Hand Model

    Professional Hand Model A.K.A ‘Golden Hands’

    Joined:
    Apr 29, 2018
    Member:
    #14878
    Messages:
    15,007
    Gender:
    Male
    First Name:
    Fred
    ‘Somewhere’... a State of Mind
    Vehicle:
    2002 Tundra SR5 4WD 4.7L AC Silver Metallica
    Hand Protectors
  3. May 21, 2020 at 7:06 PM
    #3
    glowblue

    glowblue From time to time

    Joined:
    Mar 28, 2019
    Member:
    #28267
    Messages:
    1,941
    Gender:
    Male
    First Name:
    Brian
    VA
    Vehicle:
    2021 Tundra SR5 —> 2021 F-250 XLT
    I put in the same combo. Stock set up had 2” I’d rake. My 6112s were set to 1.9”, and added 2 shims on driver side and 1 on passenger, and installed my Toytec shackles at the 1” setting and I have exactly 1” of rake Which is just what I wanted. If you set your 6112s to the highest setting, you might be very close to level, maybe need a shim.

    Rear shocks should be fine. If you go above 2.5” in the front you might need a diff drop installed.

  4. May 21, 2020 at 7:35 PM
    #4
    bmf4069

    bmf4069 Yup, that's car parts in a dishwasher

    Joined:
    Sep 1, 2018
    Member:
    #18880
    Messages:
    7,273
    Gender:
    Male
    TX
    Vehicle:
    02 AC sr5 4wd v8
    Ahem:


    Urinal Etiquette 21042019071536.jpg

    noahrexion likes this.
